(NPT) National-Pipe-Thread

21 Results

Sort:

Manufacturercutting materialcutting edge diameter [mm]Usable length [mm]Thread typeThreads [per inch]Thread pitch min.[mm]Thread pitch max [mm]Threads [per inch]Cutting directionToleranceCoatingInternal coolingNumber of cutting edges [n]

AT-1 11.67mm (P=NPT18) Thread milling cutter for internal threads Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 11.67 | Usable length [mm]: 15.52 | Thread type: NPT | Threads [per inch]: 18

Details

OSGSC11.6715.52NPT1818rightYes05
AT-1 15.67mm (P=NPT14) Thread milling cutter for internal threads Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 15.67 | Usable length [mm]: 19.96 | Thread type: NPT | Threads [per inch]: 14

Details

OSGSC15.6719.96NPT1414rightYes05
AT-1 19.67mm (P=NPT11-1/2) Thread milling cutter for internal threads Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 18.72 | Usable length [mm]: 28.7 | Thread type: NPT | Threads [per inch]: 11.5

Details

OSGSC18.7228.7NPT11.511.5rightYes06
AT-1 5.67mm (P=NPT27) Thread milling cutter for internal threads Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 5.67 | Usable length [mm]: 10.35 | Thread type: NPT | Threads [per inch]: 27

Details

OSGSC5.6710.35NPT2727rightYes04
AT-1 7.67mm (P=NPT27) Thread milling cutter for internal threads Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 7.67 | Usable length [mm]: 10.35 | Thread type: NPT | Threads [per inch]: 27

Details

OSGSC7.6710.35NPT2727rightYes04
AT-1 9.67mm (P=NPT18) Thread milling cutter for internal threads Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 9.67 | Usable length [mm]: 15.52 | Thread type: NPT | Threads [per inch]: 18

Details

OSGSC9.6715.52NPT1818rightYes05
33070.3 11.5 01 1-2 ThreadBurr Thread milling cutter for int./ext. threads Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 16 | Usable length [mm]: 29.82 | Thread type: NPT | Threads [per inch]: 11.5

Details

SmiCutSC1629.82NPT11.511.5rightYes04
33070.3 14 01 1/2-3/4 ThreadBurr Thread milling cutter for int./ext. threads Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 12 | Usable length [mm]: 22.86 | Thread type: NPT | Threads [per inch]: 14

Details

SmiCutSC1222.86NPT1414rightYes04
33070.3 14 02 3/4 ThreadBurr Thread milling cutter for int./ext. threads Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 16 | Usable length [mm]: 22.68 | Thread type: NPT | Threads [per inch]: 14

Details

SmiCutSC1622.68NPT1414rightYes04
PROMO

ADO-25D OSG carbide drill with coolant through

Details
33070.3 18 01 1/4-3/8 ThreadBurr Thread milling cutter for int./ext. threads Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 8 | Usable length [mm]: 16.23 | Thread type: NPT | Threads [per inch]: 18

Details

SmiCutSC816.23NPT1818rightYes03
33070.3 27 01 1/16-1/8 ThreadBurr Thread milling cutter for int./ext. threads Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 6 | Usable length [mm]: 10.82 | Thread type: NPT | Threads [per inch]: 27

Details

SmiCutSC610.82NPT2727rightYes03
33070.3 27 02 1/16-1/8 6L ThreadBurr Thread milling cutter for int./ext. threads Vibration-Free Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 6 | Usable length [mm]: 10.82 | Thread type: NPT | Threads [per inch]: 27

Details

SmiCutSC610.82NPT2727rightYes06
33070.3 8 01 >21/2 ThreadBurr Thread milling cutter for int./ext. threads Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 20 | Usable length [mm]: 42.86 | Thread type: NPT | Threads [per inch]: 8

Details

SmiCutSC2042.86NPT88rightYes04
33070.3 11.5 02 1-2 6L ThreadBurr Thread milling cutter for int./ext. threads Vibration-Free Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 16 | Usable length [mm]: 29.82 | Thread type: NPT | Threads [per inch]: 11.5

Details

SmiCutSC1629.82NPT11.511.5rightYes06
33070.3 14 03 1/2-3/4 6L ThreadBurr Thread milling cutter for int./ext. threads Vibration-Free Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 12 | Usable length [mm]: 22.68 | Thread type: NPT | Threads [per inch]: 14

Details

SmiCutSC1222.68NPT1414rightYes06
33070.3 14 04 3/4 5L ThreadBurr Thread milling cutter for int./ext. threads Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 16 | Usable length [mm]: 22.68 | Thread type: NPT | Threads [per inch]: 14

Details

SmiCutSC1622.68NPT1414rightYes05
33070.3 18 02 1/4-3/8 6L ThreadBurr Thread milling cutter for int./ext. threads Vibration-Free Manufacturer: SmiCut | cutting material: SC | cutting edge diameter [mm]: 8 | Usable length [mm]: 16.23 | Thread type: NPT | Threads [per inch]: 18

Details

SmiCutSC816.23NPT1818rightYes06

Sie haben 17 von 21 Produkten gesehen
