(G) inch thread

21 Results

Sort:

Manufacturercutting materialcutting edge diameter [mm]Usable length [mm]Thread typeThread pitch [mm]Thread pitch min.[mm]Thread pitch max [mm]Threads [per inch]Cutting directionTolerance classCoatingInternal coolingNumber of cutting edges [n]

33062.3 11 01 G1-11/2 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 12 | Usable length [mm]: 26.55 | Thread type: G

Details

Article available

CHF 272.00

vb toolsSC1226.55G11rightYes03
33062.3 11 02 G1-3 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 16 | Usable length [mm]: 40.41 | Thread type: G

Details

Article available

CHF 390.00

vb toolsSC1640.41G11rightYes04
33062.3 11 03 G>1 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 20 | Usable length [mm]: 49.65 | Thread type: G

Details

Article available

CHF 499.00

vb toolsSC2049.65G11rightYes05
33062.3 14 01 G1/2-7/8 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 12 | Usable length [mm]: 20.86 | Thread type: G

Details

Article available

CHF 271.00

vb toolsSC1220.86G14rightYes04
33062.3 14 02 G1/2-7/8 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 12 | Usable length [mm]: 28.12 | Thread type: G

Details

Article available

CHF 298.00

vb toolsSC1228.12G14rightYes04
33062.3 14 03 G1/2-7/8 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 16 | Usable length [mm]: 28.12 | Thread type: G

Details

Article available

CHF 390.00

vb toolsSC1628.12G14rightYes05
33062.3 19 01 G1/4-3/8 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 8 | Usable length [mm]: 15.37 | Thread type: G

Details

Article available

CHF 205.00

vb toolsSC815.37G19rightYes03
33062.3 19 02 G1/4-3/8 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 10 | Usable length [mm]: 22.06 | Thread type: G

Details

Article available

CHF 252.00

vb toolsSC1022.06G19rightYes04
33062.3 28 01 G1/8 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 6 | Usable length [mm]: 10.43 | Thread type: G

Details

Article available

CHF 170.00

vb toolsSC610.43G28rightYes03
33112.3 11.5 1 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 16 | Usable length [mm]: 29.82 | Thread type: NPSF

Details

Article available

CHF 430.00

vb toolsSC1629.82NPSF11.5rightYes04
33112.3 14 1/2-3/4 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 12 | Usable length [mm]: 22.68 | Thread type: NPSF

Details

Article available

CHF 298.00

vb toolsSC1222.68NPSF14rightYes04
33112.3 18 1/4-3/8 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 8 | Usable length [mm]: 16.23 | Thread type: NPSF

Details

Not in stock

CHF 227.00

vb toolsSC816.23NPSF18rightYes03
33112.3 27 1/16-1/8 Thread milling cutter for internal/external threads TiAlCN Coating Manufacturer: vb tools | cutting material: SC | cutting edge diameter [mm]: 6 | Usable length [mm]: 12.7 | Thread type: NPSF

Details

Not in stock

CHF 185.00

vb toolsSC612.7NPSF27rightYes03
WX-PNC 10mm (P=G19) thread milling cutter for pipe threads WX coating Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 10 | Usable length [mm]: 20.1 | Thread type: Rp

Details

Item available in 2-3 working days

CHF 174.00

OSGSC1020.1Rp19rightYes04
WX-PNC 11mm (P=G19) thread milling cutter for pipe threads WX coating Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 11 | Usable length [mm]: 26.7 | Thread type: Rp

Details

Item available in 2-3 working days

CHF 210.00

OSGSC1126.7Rp19rightYes04
WX-PNC 5.9mm (P=G28) thread milling cutter for pipe threads WX coating Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 5.9 | Usable length [mm]: 11.8 | Thread type: Rp

Details

Item available in 2-3 working days

CHF 139.00

OSGSC5.911.8Rp28rightYes03
WX-PNC 7.5mm (P=G28) thread milling cutter for pipe threads WX coating Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 7.5 | Usable length [mm]: 14.5 | Thread type: Rp

Details

Item available in 2-3 working days

CHF 139.00

OSGSC7.514.5Rp4.228rightYes03
WX-ST-PNC-3P 10mm (P=G19) thread milling cutter for pipe threads chamfer length 3P WXS coating Manufacturer: OSG | cutting material: SC | cutting edge diameter [mm]: 10 | Usable length [mm]: 30 | Thread type: G

Details

Item available in 2-3 working days

CHF 218.00

OSGSC1030G19rightYes05
